Sistem POS Touchscreen Posiflex XT 3815

Sistem POS Touchscreen Posiflex XT 3815

Processor Intel Bay Trail J1900 Quad Core, up to 2.42 GHz, 2M Cache

System Memory DDR3L SO-DIMM x 1, max. 8GB

Storage Device SATA x 2 (one for HDD/SSD; the other for 1” SSD only); Optional eMMC module

Power Supply 12V/60W

OS Support Windows 7/POSReady 7/Windows Embedded 8.1 Industry/Windows 10 IoT/Linux per request

Display & Touch

LCD 15" TFT LCD

Resolution 1024 x 768

Touch True-flat PCAP touch with multi-touch support (IP65 on front panel)

I/O Expansion

Serial Port 4, DB9 x 3 + RJ50 x 1, 5V/12V support on all 4 COM ports

Parallel Port 1, via optional conversion cable through service window

Standard USB Port 7, USB 3.0 x 1 + USB 2.0 x 6

PoweredUSB Port Optional 24V x 1 + 12V x 3 via GEN8E base

LAN Port 10/100/1000 Mb x 1

Display Port VGA x 1, 12V support for Posiflex monitors

CR Port 1, control 2 CR via optional Y-cable, supporting 12V cash drawer

PS/2 Port 1, via optional conversion cable through service window

UPS Port Yes, battery optional

AudioInternal 2W speaker x 1

Expansion Slot Mini-PCIe slot x 1

Physical Dimension

Dimension (W x D x H in mm) 372 x 320 x 252.7

Weight (N. W. in kg) 5.6

Environmental

Operating Condition 0°C - 40°C, 20%RH - 90%RH (Equipped with HDD);

0°C - 50°C, 20%RH - 90%RH (Equipped with SSD)

Storage Condition -20°C - 70°C, 10%RH - 90%RH

Built-in Options

WiFi Mini-PCIe WiFi/BT module

Attachment Options

POS Monitor Non-touch TFT LCD: 7"/9.7"/12.1"/14"/15";

PCAP touch TFT LCD: 9.7"/14"/15";

Resistive touch TFT LCD: 15"

Line Display 2 x 20 rear-mount VFD/LCD customer line display;

7" color LCD graphical customer line display
